Belimo CMU Series User Manual

2
V4. 12. 2010
.
Subject to modification
Torque
General Damper Actuator
40Nm
G
20Nm
S
10Nm
N
5Nm
L
2Nm C
General Damper Actuator
M
Power Supply
AC/DC 24V 24
AC 100...240V (AC 230 for Mechanical Fail-Safe Damper Actuator) 230
For customising types of Damper Actuators please contact your nearest Belimo sales representative.
New Generation General Damper Actuator for Asia Pacific
Damper Actuator standard type naming
Mechanical Fail-Safe Damper Actuator
20Nm
S
10Nm
N
4Nm
L
2Nm T
Mechanical Fail-Safe Damper Actuator
F
General Damper Actuator
Open/Close, 3-point
Open/Close (only for CMU230..)
Blank
Modulating DC 2(0)...10V Control -SR
-RES
Auxiliary Switch -S
Form fit -F
Terminal Connection -T
Open/Close Blank
Modulating DC 2(0)...10V Control -SR
Auxiliary Switch -S, -S2
3-point -3
Mechanical Fail-Safe Damper Actuator
Product Naming L M U 24 -SR

Belimo CMU Series Specifications

General

Brand	Belimo
Model	CMU Series
Category	Controller
Language	English
