BSD1 Door Controller Switch Settings
Talking Time/Videophone Active DIP SW1 (1-4)
4
3
2
1
Talk Time
On
On
On
On
15s
On
On
On
Off
20s
On
On
Off
On
30s
On
On
Off
Off
45s
On
Off
On
On
60s
On
Off
On
Off
75s
On
Off
Off
On
90s
On
Off
Off
Off
120s
Off
On
On
On
150s
Off
On
On
Off
180s
Other settings
60s
Off
Off
Off
Off
60s*
*Default setting
Ringing Time/Call Time and Ring Effect DIP SW1 (5-8)
8
7
6
5
Call Time
Ring Cadence or Sound Effect
On
On
On
On
5s
1 in 3 – 1 ring every 3 seconds
On
On
On
Off
8s
1 in 3 – 1 ring every 3 seconds
On
On
Off
On
10s
1 in 3 – 1 ring every 3 seconds
On
On
Off
Off
15s
1 in 3 – 1 ring every 3 seconds
On
Off
On
On
20s
1 in 3 – 1 ring every 3 seconds
On
Off
On
Off
30s
1 in 3 – 1 ring every 3 seconds
On
Off
Off
On
40s
1 in 3 – 1 ring every 3 seconds
On
Off
Off
Off
45s
1 in 3 – 1 ring every 3 seconds
Off
On
On
On
50s
1 in 3 – 1 ring every 3 seconds
Off
On
On
Off
60s
1 in 3 – 1 ring every 3 seconds
Off
On
Off
On
30s
1 in 3 (Reserved For future use)
Off
On
Off
Off
30s
1 in 3 (Reserved For future use)
Off
Off
On
On
30s
2 in 15 – 2 rings, 15S silence, repeat
Off
Off
On
Off
30s
1 in 15 – 1 ring, 15S silence, repeat
Off
Off
Off
On
30s
1 in 5 – 1 ring every 5 seconds
Off
Off
Off
Off
30s*
1 in 3* – 1 ring every 3 seconds
*Default setting
