bell issimo 1 Way Video Entry System
PD-097 Issue 4 Installation and Operating Manual Page 20 of 40
BS Videophone Switch Settings
Mute Time Settings (1-4)
4
3
2
1
Mute Time
On
On
On
On
Disabled¹
On
On
On
Off
2 minutes
On
On
Off
On
5 minutes
On
On
Off
Off
10 minutes
On
Off
On
On
15 minutes
On
Off
On
Off
20 minutes
On
Off
Off
On
30 minutes
On
Off
Off
Off
45 minutes
Off
On
On
On
1 hour
Off
On
On
Off
2 hours
Off
On
Off
On
4 hours
Off
On
Off
Off
5 hours
Off
Off
On
On
6 hours
Off
Off
On
Off
8 hours
Off
Off
Off
On
10 hours
Off
Off
Off
Off
*Indefinite²
*Default setting
¹Disabled means pressing the mute button has no effect.
²Indefinite; the mute is cancelled by pressing the button again.
Individual Functions Settings (5-8)
5
Master / Extension
Which videophone to set
*Off
Master
Only or first videophone per BSC4 output.
On
Extension / Slave
Second and subsequent videophones per BSC4 output.
6
Auto Display on Ring
Videophone display behaviour
*Off
Display during ring
Picture is on while ringing, stays on when answered.
On
No display during ring
Picture is off while ringing, comes on when answered.
7
Spare
*Off
On
8
Spare
*Off
On
*Default setting
Video Terminator Jumper Setting
The jumper is situated above the input connector. It is 3 pin and labelled On and Off.
The jumper should be on when there is only one videophone Otherwise only the last
videophone should have a jumper set to On the rest being set to Off.
Settings
(QWERGHJK)
OFF ↔ ON
Settings
(ASDFTYUI)
OFF ↔ ON
