Bell System Bellissimo BSD1 - Bsd1 Door Controller Jumper Settings

bell issimo 1 Way Video Entry System
PD-097 Issue 4 Installation and Operating Manual Page 19 of 40
Below are a couple of examples and a blank table for your use.
Example 1: -
Entrance
number
# Cameras at
this entrance
First Camera
DIP SW3 (1-4)
Last Camera
DIP SW3 (5-8)
A
2
1
5
B
1
3
5
C
2
4
5
Example 2: -
Entrance
# Cameras at
this entrance
First Camera
DIP SW3 (1-4)
Last Camera
DIP SW3 (5-8)
A
1
1
3
B
2
2
3
Customer’s setup: -
Entrance
# Cameras at
this entrance
First Camera
DIP SW3 (1-4)
Last Camera
DIP SW3 (5-8)
A
B
C
D
E
F
G
H
I
J
K
L
BSD1 Door Controller Jumper Settings
Camera Terminator
There is a separate jumper for both video Camera inputs. This has three settings, 75R for
terminating coaxial cable, 100R for terminating twisted pair Cat5 cable and None for use
when passing the cable on to another device or controller.
Video Gain Control
The “Video Gain” jumper on door controllers should always be set to “0” unless directed by
‘Bell System Technical Support’. This jumper is only required on some systems with very
long camera to videophone cable runs well in excess of 150m. Inappropriate use of this
jumper with short runs will cause picture problems.
Reassurance tones
DDA reassurance tones are activated by placing a jumper between pins 1 & 2 of the
“Prog” 5 pin header on the BSD1controller PCB (see diagram on page 30), the jumper is
stored between pins 4 & 5. Once activated the speaker in the door panel will ring with the
videophone and buzz when the lock is opened from the videophone.
