bell issimo 1 Way Video Entry System
PD-097 Issue 4 Installation and Operating Manual Page 25 of 40
PS4 Power Supply
Size
236mm x 105mm x 81mm
Output Voltage (regulated)
13.5V d.c. min, 13.8V d.c. nom, 14.1V d.c. max
Output Current
3A continuous, 4A peak (5 minutes max)
Mains Supply Internal Fuse
Not user replaceable
Supply Voltage
230V 50Hz nominal
Temperature Range
0 ºC to 50 ºC
340C Power Supply
Size
140mm x 60mm x 53mm
Output Voltage (regulated)
13.5V Min, 13.8V Nom, 14.1V Max
Output Current
1A continuous, 1.5A peak (5 minutes max)
Mains Supply Internal Fuse
Not user replaceable
Supply Voltage
230V 50Hz nominal
Temperature Range
0 ºC to 50 ºC
840 Power Supply – Battery Backed
Size
350mm x 330mm x 80mm
Output Voltage (regulated)
13.5V Min, 13.8V Nom, 14.1V Max
Output Current
3A continuous, 4A peak (5 minutes max)
Mains Supply Internal Fuse
T2A 20mm HBC (HRC) Ceramic
Battery Fuse
F4A 20mm Glass
Supply Voltage
230V 50Hz nominal
Temperature Range
0 ºC to 50 ºC
