9
6. Rest the lid on the auger spindle so that the lid’s locking tab sits slightly to the right
of the black bar. (See Figure 6.)
7. Grasping the Cold Press Juicer rmly by the motor base handle in one hand, grasp the
hopper to turn the lid clockwise. The lid is locked when the locking tab is fully inserted into
the handle slot in the upper rim of the processing bowl and is perfectly aligned with the black bar.
(See Figure 7.)
8. Place either handled cup under the juice spout. Place the second cup under the pulp spout
at the back of the Cold Press Juicer. Your Cold Press Juicer is completely assembled and ready
for juicing! (See Figure 8.)
IMPORTANT: The Cold Press Juicer’s safety system prevents the unit from being turned ON
unless it is completely and properly assembled.
FIGURE 7FIGURE 6 FIGURE 8
Locking Tab
Handle Slot
Black Bar
