Belling BI60FP - Installation - 60 CM

INSTALLATION - 60CM
i)Wheninstalledinatypical600mmdeep
built in housing unit, the false back should
be removed from the housing unit to
provide the necessary depth for
installation.
ii)Whenthefalsebackisremoved,itis
normally the case that the support shelf
for the appliance leaves a gap between
the back edge and the wall of
approximately 80mm.
iii)Ifnogapoccursbetweentheback
edge of the shelf and the wall behind the
unit, we recommend that a gap of at least
30mm is made by shortening the shelf.
iv)Wheninstallingtheappliancebelowa
worktop, there must be a minimum
ventilation area of 60cm2 below the
appliance,ineitherarea(1)or(2),as
indicated below. There must be a 5mm
gap between the front top edge of the
oven and the underside of the worktop.
Important: Do not modify the outer panels
of this appliance in any way.
Ensure that you route all mains electrical
cablesandexibletubingwellclearofany
adjacent heat source, such as an oven,
grill or hob.
Ensure that all pipe work is of the correct
rating for both size and temperature.
Installing the appliance under a
worktop
Where the appliance is installed under
a worktop, with a hob installed above it,
the installation instructions for the hob
must be read in conjunction with these
instructions.
