Fitting the towel rail (if applicable)
• On the towel rail there are two holes, top (A) and bottom (B), these holes have corresponding holes
on the fascia at each end.
• Both screws must be inserted through the towel rail at each end and screwed into the fascia. Both
screws are M6 screws but the longer screw must be secured through the top hole. Using the Allen
key provided, tighten the screws making sure that the towel rail is ush to the fascia, but not over
tightened.
A
B
Vinyl wrapped surfaces (if applicable)
BEFORE INSTALLATION
If this appliance is installed near vinyl wrapped
surfaces, we strongly recommend using an
installation kit available from the vinyl-wrap
supplier. Belling cannot accept any
responsibility for damage caused due to
installation into cabinets with low temperature
tolerances.
This appliance shall be installed in accordance with AS/NZS 5601 Gas Installations Fig 5.1:Required
Clearances Around Domestic Cooking Appliances.
Any adjoining wall surface situated within 200mm from the edge of any burner must be a suitable
non-combustible material for a height of 150mm for the entire length of the appliance. Any
combustible construction above the appliance must be at least 600mm above the top of the cooking
surface and no construction shall be within 450mm above the top of the cooking surface.
If a bench made from a combustible material is situated within 200mm from the edge of any burner,
it should be 10mm or more below the hob. Install rangehoods in accordance with manufacturers
instructions, no closer than 600mm above the cooking surface for Rangehoods and 750mm for
Exhaust Fans.
