Cupboard / hood clearances
Nominal width of the hob
90mm
Wall Unit Wall Unit
400mm
No shelf or overhang of
combustible material should be
closer than 650mm above the hob.
90mm
10mm
400mm
min
650mm
worktop worktop
10mm
View from front
Worktop Worktop
10mm 10mm
60mm
• If your appliance has a side opening door, we recommend a side clearance of 60mm to allow the
oven door to fully open, if placed up to a wall or cabinetry.
• The cooker must have a side clearance above hob level of 90mm up to a height of 400mm.
DIMENSIONS AND CLEARANCES
View from above, with the
appliance located in a corner
