Belling BRD900DF - BEFOREINSTALLATION; Levelling Your Cooker; Fitting the plinth

Levelling Your Cooker
Place a spirit level on a baking sheet onto an oven shelf.
The cooker is tted with leveling feet (1) Level your cooker to your desired height using the leveling feet
at the front and rear of the cooker.
Rearwheels(iftted)
Adjustment of the wheel height can be made with a screw driver, through the hexagonal hole in the
front plinth
Fitting the plinth
• Make sure the appliance is raised to a height of 915mm or above before beginning. If the appliance
is below 915mm - you can only t the plinth cover labelled X. You can adjust the height using the
feet (1) of the appliance. If your appliance has a storage drawer at the bottom, you access the re-
quired holes through the base of the drawer after lifting the mat.
• Open the appliance doors, and loosen screw A located on bracket (2). Do not remove this screw
entirely
• Insert screw B, through slot (3) and screw into the small hole at the bottom of bracket (2). Make sure
that the plinth cover is ush to the appliance, but not over tightened.
Oven cavity
Door
X
Y
A
B
(1)
(2)
(3)
Plinth Cover
BEFORE INSTALLATION
