Control Panel
Front Centre
Hotplate 1.8kW
Warming Zone
On/Off Switch
Grill
Control
Fan Oven
Neon
Fan Oven
Thermostat
Electronic Timer /
Programmer
(Fan Oven only)
Front Right
Hotplate 1.5kW
Right Sealed
Hotplate 1.5kW
Slow Cook Oven
On/Off Switch
Slow Cook /
Warming Oven
Neon
Conventional
Oven Neon
Rear Right
Hotplate 1.2kW
Conventional Oven
Thermostat
Warming
zone neon
Hob Hot
Neon
Right Sealed
Hotplate Neon
Front Left
Hotplate 1.5kW
Rear Left
Hotplate 1.2kW
In common with all cookers having controls sited above the grill
compartment, care must be taken when setting the controls, due
to the hot air expelled from the grill compartment.
To keep the controls cool when the appliance is used, a gentle flow
of air will be blown from beneath the control panel.
If the appliance is still warm, this cooling fan may run on or restart
itself when all the controls have been turned off. This is normal
and is NOT a fault.
The fan will stop once the appliance has cooled.
The oven light will illuminate when the oven control is operated.
The light will remain on during the cooking period.
Operating
controls when
the grill is in use
Cooling fan
Oven light
11
