7
6) REMOVAL OF FACIA PANEL
CARRY OUT BOTH OPERATIONS IN
STEP 5 (REMOVAL OF SIDE PANELS)
REMOVE ALL CONTROL KNOBS
REMOVE 4 X HOLDING SCREWS 2
ON EACH SIDE
AND REMOVE THE FACIA PANEL
7) REMOVING THE REAR SERVICE PANEL
REMOVE SECURING SCREWS X6
REMOVE REAR SERVICE PANEL
WITH CARE SO AS NOT TO
DISCONNECT ANY OF THE WIRES
CONNECTED TO THE TERMINAL
BLOCK
