Belling FSDF 60 DO - Gas Hob Automatic Ignition Fault Diagnosis

Faulty ignition (Automatic ignition)
Customer states no ignition to burner/s
NO
YES
YES
NO
YES NO
NO
YES
Is more than one
burner affected?
Can you see a
spark at the burner?
Replace
electrode and or ignition
switch
(
micro switch
)
clean and make sure
burnerskirt and cap are
fitted correctly.
If this does not work.
Are all four
burners affected
check electric supply to
hob?
Replace spark
generator
Replace electrodes as
required andIgnition switch
(micro switch)
