6
5) REMOVAL OF FACIA PANEL
REMOVE ALL CONTROL KNOBS
REMOVE 2 X HOLDING SCREWS
AND REMOVE THE FACIA PANEL
TAKE CARE NOT TO DAMAGE
THE NEONS ON REMOVAL
6) REMOVING THE REAR SERVICE PANEL
REMOVE SECURING SCREWS X6
REMOVE REAR SERVICE PANEL
WITH CARE SO AS NOT TO
DISCONNECT ANY OF THE WIRES
CONNECTED TO THE TERMINAL
BLOCK
