10
E) GRILL ELEMENT
FOLLOW STEP 6 REMOVE REAR SER-
VICE PANEL
DISCONNECT WIRES
REMOVE GRILL ELEMENT GUARD BY
LOOSENING 2 HIDDEN SCREWS
(POSITIONS INDICATED ) AND
SLIDING OFF
REMOVE THE 2 SCREWS SECURING
THE ELEMENT BRACKET TO THE
CAVITY AND PULL THE ELEMENT
FORWARD TO REMOVE
D) THERMOSTATS
FOLLOW STEP 3 AND REMOVE THE
HOB TOP
PULL THE T/STAT FROM THE SWITCH
HOUSING
REMOVE THE T/STAT PHIAL FROM
THE RELEVANT OVEN CAVITY AND
PULL THROUGH
T/O T/STAT M/O T/STAT
