general Settings (CONT.)
system setup (CONT.)
5. Panel (Touch panel calibration) - Calibrate the screen and adjust the brightness
• Brightness - Set the brightness dimmer by sliding the icon
• Touch panel calibration - Calibrate the screen by tapping the crosses in the order they
appear: top left, top right, bottom left, bottom right, then the center. After that, the
calibration will be complete and you can hit the back button to exit.
6. Radio regional settings - Select your region. “North America” will be selected by default
7. Wallpaper - Select between 12 different wallpaper options
8. Time & date - Adjust time & date of the stereo
• Year, month, & day - adjust the following with the up and down arrows
• Hour, minute, & second - adjust the following with the up and down arrows
• You can also enable a 24 hour clock system by hitting the checkbox
• Once you are done making adjustments, hit the icon to exit
9. SWC (Steering Wheel Control) - Adjust the controls steering wheel to correspond with
different actions.
IM POR TANT: You must have a SWC retention adapter to retain your steering wheel controls.
Steps for setting button functions:
Steps for setting button functions:
1. Press and hold the first button on the steering wheel and touch the selected
function icon on the screen. When the icon on the screen turns gray, release the
button on steering wheel.
2. Repeat step one for the other buttons you want to use and each should turn
different colors once they are assigned to a particular button on the steering
wheel.
3. If you want to delete any of the assigned keys touch the to clear the
assigned functions
4. When all button are assigned the way you prefer, tap the icon to save
and exit
10. About - Click here to see what software version the head unit is using
