• Für alle mechanischen Eingriffe, insbesondere im Garantiezeitraum, gilt die Empfehlung, sich an die Fachwerkstätten unserer
Vertragshändler zu wenden.
ACHTUNG ! ! ES WIRD EMPFOHLEN, DEN MOTOR NICHT LAUFEN ZU LASSEN, WENN DIE MACHINE NICHT FÜR
DIE ARBEIT VERWENDET WIRD.
TECHNICAL DETAILS
FOR THE ENGINE FEATURES SEE THE ENGINE INSTRUCTION BOOKLET DELIVERED WITH THE MACHINE.
• Acoustic power level LwA = from 93 LdB (A) to 94 LdB (A)
• Acoustic pressure to the operator’s ear: LpA = 80 dB (A)
• Vibration to handlebar with weighting UNI EN 1033 value: from 3,23 m/sec² to 4,99 m/sec²
Test condition: 1,6 Mt in the middle of the handlebar
The engine fitted on this cultivator have following features:
• Exhaust guard (Pict. 1 Ref. “A”)
• Recoil starter
• Dry air filter
• ENGINE LUBRICATION WITH: see instruction manual of the engine.
• Quantity of engine oil: see instruction manual of the engine.
• Fuel : unleaded petrol
• Safety device for both forward and backward gear stopping the tiller.
• The model BL300 has a single belt transmission for the engine and a greased chain for the tiller.
• The model BL350 has a double belt transmission (front and reverse) for the engine and a greased chain for the tiller.
• The handlebar can be:
1. adjustable in 3 vertical positions
2. adjustable in different positions (height and side)
• The tiller can be of 57 cm or 80 cm.
• The gear-box is screwed (Pict. 2).
• The spur can be adjustable (Pict 3 Ref. “B”) or fixed (see Pict 4).
All the identification references (code number, engine, weight, power) are printed on the number plate on the machine (Pict. 6
Ref. “D”).
INSTRUCTIONS FOR MOTORHOE ASSEMBLY
The machine is packed in a box of the following dimensions :
◊ WIDTH: 80 cm. ◊ HEIGHT: 70 cm. ◊ LENGHT: 45 cm.
• Take the machine out of the carton box.
• Fit the two tillers to the main shaft using the delivered screws and nuts.
• Fit the rear spur in its place using the delivered bolt and both pins which are on the spur holder.
• Fit the handlebar on the support:
- The model with the vertical adjustment is fitted with two screws and nuts already fitted on the handlebar.
- The model with the full-side adjustment (rack, wheel system) is fitted with the parts already mounted on the handlebar holder.
• The front wheel holder is fitted to the frame by means of two pins with cotter and spring. The small wheel has to be fitted on the
holder through screw and nut. To put the small wheel in the requested position pull outwards till the pin is completely inside the
buttonhole (see picture n.7).
• Fit the two guard-extensions to the main tiller protections fitted on the body of the machine using the proper screws and nuts. The
protection guards should reach a width of 60 cm according to CE norms.
• To make the transport easier it is possible to keep the handlebar disassembled, by means of the two screws in one version or by
means of the thread bushing in the other one, that fix it to the handlebar holder.
