19
Suction Head
Suction head is the height to which a pump can raise water on the suction side,
measured from the water level in the sump. Discharge head is the vertical distance
between the intake level of the water pump and the level at which it discharges
water freely. Total head is the sum of the suction and discharge head.
Discharge Head
Suction Head
7m (23’) max
Total Head
Good PlacementBad Placement
BP SERIES
