38
7. SPECIFICATIONS
Model BP271 BP371
Pump Type Water Transfer Water Transfer
Pump Size 2” 3”
Fuel Tank Capacity 1Gal / 3.6 L 1Gal / 3.6 L
Fuel Type Recommended
Ethanol Free
91+ Octane
Ethanol Free
91+ Octane
Oil Capacity 20 oz. / 600 ml 20 oz. / 600ml
Oil Type Recommended SAE 10W-30 SAE 10W-30
Engine 7HP OHV 7HP OHV
Engine Displacement 212 cc 212 cc
Engine Bore x Stroke 70 x 55 mm 70 x 55 mm
Maximum
Engine Speed
3600 rpm 3600 rpm
Max Flow Rate 450 Liters / min. 950 Liters / min.
Total Head Lift 105 ft. / 32 m 92 ft. / 28 m
Suction Head Lift 23 ft. / 7 m 23 ft. / 7 m
Max Solids Handling 0.16 in / 4 mm 0.24 in / 6 mm
Operating Temperature 0 - 40 °C 0 - 40 °C
Weight 57.2 lbs / 26 Kg 60.5 lbs / 27.5 Kg
Dimensions (L*W*H) 21.9 x 22.2 x 18.9 in 21.9 x 22.2 x 18.9 in
