28
5.2 CHANGING THE OIL
WARNING!
Used motor oil can cause skin irritations if left in long-term
contact with skin. Wash hands thoroughly with soap and water
after handling oil.
Note
Do not dispose of used oil in drains or on soil. Local service shops
provide environmentally-friendly disposal methods.
1. Stop the engine and remove the dipstick.
2. Place a pan under the engine.
3. Remove the oil drain plug and allow the oil to completely drain into the pan.
OIL LEVEL
Wing nut
Air Cleaner Cover
Air Filter
Grid
Electrode Gap
0.028 - 0.031 in
(0.7 - 0.8 mm)
Spark Plug
OIL LEVEL
Wing nut
Air Cleaner Cover
Air Filter
Grid
Electrode Gap
0.028 - 0.031 in
(0.7 - 0.8 mm)
Spark Plug
