BENDIX TABS-6 TRAILER ABS MODULE User Manual

10
Display Conguration
To check the ABS conguration, apply ignition power
and depress / release the brake pedal 6 times within 15
seconds. Following activation, there will be a 5-second
delay followed by a blink code display of the module's
current ABS conguration.
CHART 6 – ABS COnFIGURATIOnS
Display Odometer Mileage
To display the trailer odometer mileage, apply ignition
power and depress / release the brake pedal 7 times within
15 seconds. Following activation, there will be a 5-second
delay followed by a blink code display of the odometer
information (x1000).
Example: 152,431 miles will be displayed as: 152 (x1000)
or 1 blink (pause), 5 blinks (pause), 2 blinks.
Zeros will be displayed by the ABS indicator lamp strobing
twice.
Odometer mileage cannot be altered with blink code
diagnostics. Complete odometer information can be
retrieved using a diagnostic tool.
Resetting ABS Conguration
To reset the ABS conguration to the default conguration,
apply ignition power and depress / release the brake
pedal 8 times within 15 seconds. Following activation,
the TABS-6 ABS conguration will reset to the default ABS
conguration (2S/1M).
1st Digit Sensors
2 2 Sensors
4 4 Sensors
2nd Digit Modulators
1 1 Modulator
2 2 Modulators
3 3 Modulators
3rd Digit ABS Control Mode
1 Axle
2 Side
3 Dolly-Axle
4 MOD1 Axle - MOD2 Dolly-Axle
5 MOD1 Axle - MOD2 Lift Axle
6 Side (MOD1, MOD2) - MOD3 Dolly-Axle
Diagnostic Trouble Codes (DTCs)
1st 2nd Fault Description Repair Information J1587 J1587
Digit Digit (SID) (FMI)
1 1 No faults • ABS system fully operational – no faults detected 1 0
WHEEL SPEED SENSORS (WSS)
2 1 SL Sensor signal valid - large air gap 1 0
3 1 SR Sensor signal valid - large air gap 2 0
4 1 SAL Sensor signal valid - large air gap 3 0
5 1 SAR Sensor signal valid - large air gap 4 0
2 2 SL Sensor signal valid - loss of signal 1 1
3 2 SR Sensor signal valid - loss of signal Dynamic Wheel Speed Sensor Fault. 2 1
4 2 SAL Sensor signal valid - loss of signal Go to Section G, on Page 29. 3 1
5 2 SAR Sensor signal valid - loss of signal 4 1
2 3 SL Sensor signal valid – noisy 1 2
3 3 SR Sensor signal valid – noisy 2 2
4 3 SAL Sensor signal valid – noisy 3 2
5 3 SAR Sensor signal valid – noisy 4 2
2 4 SL Sensor shorted or open 1 4 or 5
3 4 SR Sensor shorted or open Static Wheel Speed Sensor Fault. 2 4 or 5
4 4 SAL Sensor shorted or open Go to Section G, on Page 29. 3 4 or 5
5 4 SAR Sensor shorted or open 4 4 or 5
2 5 SL Tire diameter out of range • Verify correct tire size as desired. 1 13
3 5 SR Tire diameter out of range • Verify proper tire ination. 2 13
4 5 SAL Tire diameter out of range • Verify correct number of exciter ring teeth. 3 13
5 5 SAR Tire diameter out of range • Verify that the ECU has the proper tire size settings. 4 13
4 6 SAL Sensor conguration error • Verify correct ABS conguration using blink codes 3 13
or other diagnostic tools.
5 6 SAR Sensor conguration error • If needed, reset to the default ABS conguration and 4 13
power-up to initiate auto-conguration.
