18
Troubleshooting: System Schematics
2S/1M - AXLE
CONTROL
Trailer
Chassis
Harness
ABS
Dual Axle Trailer
Bendix
SR-5™ Trailer
Spring Brake
Valve
Trailer ABS
Pigtail
Harness
5-PIN
CONNECTOR
Ignition
Power
Brake
Light
Power
Ground
7-PIN
CONNECTOR
SUPPL
Y
LINE
CONTROL
LINE
A Brake
Light Power
B Ignition
Power
C NC
D Warning
Lamp
E Ground
C
E
B
A
D
Bendix
®
TABS-6
Trailer
ABS
Module
ABS
Indicator Lamp
TABS
Bendix WS-24™
Wheel Speed
Sensor "SR"
Bendix WS-24™
Wheel Speed
Sensor "SL"
Right -
“Curb-Side”
Left -
“Road-
S
ide”
®
®
®
