B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-87
6.4.7 LCD Display Board
200-07479-0000 LCD DISPLAY BD REV AC
200-07479-0001 LCD DISPLAY BD REV AC
----------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001
----------------------------------------------------------------------
C801 106-04104-0047 CH 100KX7R/50V EA 1.00 1.00
C802 113-03121-0000 CAP DC 120PF 500V EA 1.00 1.00
CR801 007-06223-0000 DIO DUAL SWITCHING EA 1.00 1.00
CR802 007-06222-0000 DIO DAN202K EA 1.00 1.00
CR803 007-06222-0000 DIO DAN202K EA 1.00 1.00
DS802 037-00027-0001 LMP 6802AS15 T1 5V EA 1.00 1.00
DS803 037-00027-0001 LMP 6802AS15 T1 5V EA 1.00 1.00
DS804 037-00027-0001 LMP 6802AS15 T1 5V EA 1.00 1.00
DS805 037-00027-0001 LMP 6802AS15 T1 5V EA 1.00 1.00
DS806 037-00027-0001 LMP 6802AS15 T1 5V EA 1.00 1.00
DS807 037-00027-0001 LMP 6802AS15 T1 5V EA 1.00 1.00
I801 120-02254-0000 IC LCD DRIVER 40X4 EA 1.00 1.00
Q801 007-00813-0000 XSTR NPN S MMBTA14 EA 1.00 1.00
R801 139-06811-0000 RES CH 6.81K EW 1% EA 1.00 1.00
R802 133-00351-0006 POTENTIOMETER 47K EA 1.00 1.00
R803 139-02003-0000 RES CHIP 200KEW1% EA 1.00 1.00
R804 139-01001-0000 RES CHIP 1K EW 1% EA 1.00 1.00
REF1 300-07479-0000 DISPLAY BOARD RF .00 .00
REF2 002-07479-0000 LCD DISPLAY BOARD RF .00 .00
S801 133-00398-0003 POT DUAL, SW EA 1.00 1.00
009-07479-0000 PC BD LCD DSPL BD EA 1.00 1.00
012-01602-0000 TAPE, PAPER DOUBLE IN .40 .40
016-01008-0004 GLYPTAL 7526 BL AR 1.00 1.00
016-01013-0000 VAC GREASE DC 976 AR 1.00 1.00
016-01040-0000 COATING TYPE AR AR 1.00 1.00
016-01140-0000 SUPERBONDER 415 AR 1.00 1.00
016-01144-0001 ACCELERATOR 11525 AR 1.00 1.00
016-01412-0000 LOCTITE 425 AR 1.00 1.00
026-00002-0000 WIRE, CU, 24AWG, T IN 1.50 1.50
030-02490-0002 COND RBR CONN EA 1.00 1.00
030-02490-0003 COND RBR CONN EA 1.00 1.00
043-00036-0001 LCD KY96A/96A EA 1.00 1.00
047-05019-0000 SPRING SW 10POS EA 1.00 1.00
047-08221-0001 LCD MTG BRK EA 1.00 1.00
047-08608-0001 LCD RETAINER EA 1.00 1.00
076-00248-0003 SPACER .365 EA 1.00 1.00
076-03051-0002 SPOOL PART W/ FINI EA 1.00 1.00
088-00767-0001 KNOB EA 1.00 .
088-00769-0000 SLEEVE LOCKING EA 1.00 1.00
088-00770-0000 HOUSING SWITCH EA 1.00 1.00
088-00770-0001 HOUSING SWITCH EA 1.00 1.00
088-01022-0001 CONTACT ASSY EA 2.00 2.00
088-01057-0023 SHAFT W / KNOB RIN EA 1.00 .
088-02163-0000 LIGHT BLK HOLDER EA 1.00 1.00
088-02273-0001 LIGHT BLOCK, LCD EA 1.00 1.00
088-03120-0000 KNOB OUTER EA . 1.00
088-03121-0021 KNOB PAINTED EA . 1.00
089-02106-0011 NUT FLAT 1/4-32 EA 1.00 1.00
089-05519-0003 SCR FLHP 2-56X3/16 EA 7.00 7.00
089-06200-0003 SCR SET 2-56X3/32 EA 1.00 1.00
089-06689-0006 SCR PHP PLASTITE EA 2.00 2.00
089-08093-0030 WSHR FLT STD .094 EA 10.00 10.00
089-08309-0000 WASHER INSULATING EA 2.00 2.00
090-00019-0005 RING RTNR .188 EA 2.00 2.00
150-00003-0010 TUBING TFLN 24AWG IN 1.50 1.50
