BENDIXKing KY 96A - LCD Processor Board

B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-57
6.4.4 LCD Processor Board
200-07475-0000 LCD PROCESSOR BD REV 0
200-07475-0001 LCD PROC 136.975 REV 1
200-07475-0099 LCD PROC COMMON REV AB
-----------------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001 -0099
-----------------------------------------------------------------------------
C701 106-04121-0026 CAPCH120PFNPO/100V EA . . 1.00
C702 106-04473-0047 CAP CH 47K X7R/50V EA . . 1.00
C703 106-04473-0047 CAP CH 47K X7R/50V EA . . 1.00
C704 097-00108-0007 CAP EL 10UF 16V EA . . 1.00
C705 106-04473-0047 CAP CH 47K X7R/50V EA . . 1.00
C706 106-04121-0026 CAPCH120PFNPO/100V EA . . 1.00
C707 106-04154-0078 CAP CH 150KZ5U/50V EA . . 1.00
CR701 007-05117-0007 DIO Z 6.2V SOT EA . . 1.00
CR702 007-06025-0000 DIO S 1N4003 EA . . 1.00
CR703 007-06025-0000 DIO S 1N4003 EA . . 1.00
CR704 999-09999-0098 PLACE HOLDER RF . . .00
CR705 999-09999-0098 PLACE HOLDER RF . . .00
CR706 007-06105-0000 DIO HV FDH444 EA . . 1.00
CR707 007-06105-0000 DIO HV FDH444 EA . . 1.00
CR708 007-06223-0000 DIO DUAL SWITCHING EA . . 1.00
CR709 007-06181-0000 DIO DUAL MMBD2835 EA . . 1.00
CR710 007-06181-0000 DIO DUAL MMBD2835 EA . . 1.00
CR711 007-06025-0000 DIO S 1N4003 EA . . 1.00
CR712 007-06025-0000 DIO S 1N4003 EA . . 1.00
DS701 037-00034-0002 LMP 8098 T1 14V EA . . 1.00
DS702 037-00034-0002 LMP 8098 T1 14V EA . . 1.00
I701 120-03163-0001 LM2901 SO-14 COMP EA . . 1.00
I702 122-00605-9999 SOFTWARE PLACEHOLD RF . . .00
I703 120-03127-0011 IC LM2903 SO PKG EA . . 1.00
I704 120-02156-0000 16X16 BIT EEPROM EA . . 1.00
I705 123-04024-0003 IC 74HC4024 SO-14 EA . . 1.00
I706 120-03246-0000 TLC541IFN AID CONV EA . . 1.00
Q701 007-00280-0000 XSTR E176/J176 EA . . 1.00
Q702 007-00466-0000 XSTR S PNP MMBTA56 EA . . 1.00
Q703 007-00467-0000 XSTR S NPN MMBTA06 EA . . 1.00
Q704 007-00467-0000 XSTR S NPN MMBTA06 EA . . 1.00
Q705 007-00466-0000 XSTR S PNP MMBTA56 EA . . 1.00
Q706 007-00467-0000 XSTR S NPN MMBTA06 EA . . 1.00
Q707 007-00454-0000 VMOS PWRFET EA . . 1.00
Q708 007-00179-0001 XSTR SOT23 2N3904 EA . . 1.00
Q709 007-00466-0000 XSTR S PNP MMBTA56 EA . . 1.00
R701 139-02001-0000 RES CHIP 2K EW 1% EA . . 1.00
R702 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R703 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R704 139-01001-0000 RES CHIP 1K EW 1% EA . . 1.00
R705 139-05621-0000 RES CHIP 5.62KEW1% EA . . 1.00
R706 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R707 139-04751-0000 RES CH 4.75K EW 1% EA . . 1.00
R708 139-03011-0000 RES CH 3.01K EW 1% EA . . 1.00
R709 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R710 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R711 139-09092-0000 RES CHIP 90.9KEW1% EA . . 1.00
R712 131-00104-0013 RES CF 100K EW 5% EA . . 1.00
R713 136-08871-0062 RES PF 8.87K EW1% EA . . 1.00
R714 136-04872-0062 RES PF 48.7K EW 1% EA . . 1.00
R715 139-01002-0000 RES CHIP 10K EW 1% EA . . 1.00
R716 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R717 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R718 139-01002-0000 RES CHIP 10K EW 1% EA . . 1.00
R719 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R720 139-04752-0000 RES CH 47.5K EW 1% EA . . 1.00
R721 139-01002-0000 RES CHIP 10K EW 1% EA . . 1.00
