BENDIXKing KY 96A - Main Board

B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-149
6.4.10 Main Board
200-07799-0000 97A MAIN BD 25KHZ REV AB
200-07799-0001 96A MAIN BD 25KHZ REV AB
200-07799-0002 97A MAIN BD 50KHZ REV AA
200-07799-0099 COMMON BOM REV CK
------------------------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001 -0002 -0099
------------------------------------------------------------------------------------
C101 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C102 106-05399-0020 CH 3.9PF NPO/100V EA . . . 1.00
C103 106-05479-0020 CH 4.7PF NPO/100V EA . . . 1.00
C104 106-04102-0026 CH 1KPF NPO/100V EA . . . 1.00
C105 106-04471-0026 CH 470PF NPO/100V EA . . . 1.00
C107 106-04221-0026 CAP CH220PFNPO/100 EA . . . 1.00
C108 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C109 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C110 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C111 106-04682-0057 CAPCH6800PFX7R/100 EA . . . 1.00
C112 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C113 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C114 106-05689-0020 CH 6.8PF NPO/100V EA . . . 1.00
C115 106-05030-0020 CH 3.0PF NPO/100V EA . . . 1.00
C116 106-04471-0026 CH 470PF NPO/100V EA . . . 1.00
C117 106-04471-0026 CH 470PF NPO/100V EA . . . 1.00
C118 106-05060-0020 CH 6PF NPO 100V EA . . . 1.00
C119 999-09999-0098 PLACE HOLDER RF . . . .00
C120 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C121 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C122 106-00146-1R2B CAP PORC 1.2PF 500 EA 1.00 1.00 . .
C123 106-00146-1R2B CAP PORC 1.2PF 500 EA 1.00 1.00 . .
C124 106-00146-1R2B CAP PORC 1.2PF 500 EA 1.00 1.00 . .
C125 097-00108-0007 CAP EL 10UF 16V EA . . . 1.00
C126 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C127 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C128 097-00108-0007 CAP EL 10UF 16V EA . . . 1.00
C129 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C130 106-04392-0057 CAPCH3900PFX7R/100 EA . . . 1.00
C131 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C132 106-04470-0026 CAPCH 47PFNPO/100V EA . . . 1.00
C133 106-04470-0026 CAPCH 47PFNPO/100V EA . . . 1.00
C134 102-00085-0000 CAP VAR SURF MTG EA . . . 1.00
C135 097-00108-0020 CAP EL 0.47UF EA . . . 1.00
C136 106-05020-0020 CH 2PF NPO 100V EA . . . 1.00
C137 097-00108-0021 CAP EL 1.OUF 50V EA . . . 1.00
C138 106-04103-0057 CAP CH 10KX7R/100V EA . . . 1.00
C139 106-04473-0047 CAP CH 47K X7R/50V EA . . . 1.00
C140 106-04102-0026 CH 1KPF NPO/100V EA . . . 1.00
C141 106-04103-0057 CAP CH 10KX7R/100V EA 1.00 1.00 1.00 .
C142 106-04103-0057 CAP CH 10KX7R/100V EA 1.00 1.00 1.00 .
C143 106-04103-0057 CAP CH 10KX7R/100V EA 1.00 1.00 1.00 .
C144 097-00108-0021 CAP EL 1.OUF 50V EA . . . 1.00
C145 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C146 106-04220-0026 CH 22PF NPO/100V EA . . . 1.00
C147 106-05020-0020 CH 2PF NPO 100V EA . . . 1.00
C148 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C149 106-04820-0026 CAP CH82PFNPO/100V EA . . . 1.00
C150 106-04330-0026 CH 33PF NPO/100V EA . . . 1.00
C151 097-00104-0036 CAP AL 47UF 25V EA . . . 1.00
C152 097-00108-0021 CAP EL 1.OUF 50V EA . . . 1.00
C153 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C154 106-04220-0026 CH 22PF NPO/100V EA . . . 1.00
C155 106-04470-0026 CAPCH 47PFNPO/100V EA . . . 1.00
C156 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
C157 106-04121-0026 CAPCH120PFNPO/100V EA . . . 1.00
