14
6. With the shims and anchor bolts in place, tighten
by securing the nut to the base then turning 2 - 3 full
turns clockwise. DO NOT use an impact wrench for
this procedure. ( See Fig. 8 )
STEP FIVE
( Mounting The OFFSIDE column. )
1. Position the OFFSIDE column at the designated
chalk locations and secure to the floor following the
same procedures as outlined in STEP FOUR
NOTE:
To ease installation of the top beam, it helps to
keep the anchor bolts loose on one of the
columns until the top beam is mounted.
STEP SIX
( Mounting the OVERHEAD BEAM. )
1. Remove all of the Equalizer pulleys in prepa-
ration of installing the Top Trough assy.
2. Using a lifting device, raise the OVERHEAD
beam into position on top of the columns. Bolt
to the columns using the 10 mm Hex Bolts,
Nuts and Washers. YOU MUST
POSITION
THE SWITCH ENCLOSURE ADJACENT
POWERSIDE COLUMN. (Fig 9)
Fig 9
Important Note
YOU MUST POSITION THE SWITCH ENCLO-
SURE ADJACENT POWERSIDE COLUMN.
NOTE:
In order to route the equal-
izer cables the pulleys
must be removed
Fig 8
To Next Page
