18
Note:
Assymetrical models have an additional
safety pulley to route the cable out of the
path of the cylinder
5. Route the cable the same way
on the power side going back
down the post.
6. Route the cable over the top
post on the safety handle. Insert
the cable end through the hole on
the threaded post
7. Pull the slack out the safety
cable and hold tension as the
cable is being tightened.. Tighten
jam nuts on either side of the cable
to secure it into place. (Fig 17)
Fig 15
Fig 16
Fig 17
Make sure to tighten both nuts
equally so as to keep the safety
cable centered
