36
1. Check if the throttle manually-operated pull button revolves smoothly from the fully
open position to fully closed position.
2. Measure the free play of throttle control pull button at the air throttlemanually-operated
pull button ange. The standard free play should be 10°~15°.
Unscrew the locking nut (1) and turn the regulator (2) to adjust the free stroke.
ADJUSTMENT OF ACCELERATOR CABLE WIRE
