Table of contents

Safety information ............................1-1

Description..........................................2-1

• Left view................................................ 2-1

• Right view............................................ 2-2

• Controls and instruments................2-3

Instrument and control

functions............................................ 3-1

• Key.......................................................... 3-1

• Main switch/steering lock...............3-1

• Multifunction display........................3-3

• Multifunction display controls.......3-7

• Handlebar switches.........................3-11

• Clutch lever .......................................3-13

• Shift pedal...........................................3-13

• Brake lever...........................................3-13

• Brake pedal.........................................3-14

• ABS........................................................3-14

• Fuel tank cap......................................3-15

• Fuel....................................................... 3-16

• Catalytic converter...........................3-17

• Seats.....................................................3-18

• Adjusting the headlight beams...3-18

• Auxiliary USB jack............................3-19

Shock absorber setting...................3-20

• Sidestand............................................3-22

• Ignition circuit cut-o system..... 3-22

For your safety –

pre-operation checks ....................... 4-1

Operation and important

riding points.......................................5-1

• Starting the engine........................... 5-1

• Shifting.................................................. 5-2

• Tips for reducing fuel

consumption.......................................5-2

• Engine break-in...................................5-3

• Parking.................................................. 5-3

Periodic maintenance and

adjustment..........................................6-1

• Owner’s tool kit...................................6-2

• General maintenance and

lubrication chart................................ 6-3

• Checking the spark plugs............... 6-9

• Canister............................................... 6-10

• Engine oil and oil

lter cartridge ...................................6-10

• Coolant................................................6-13

• Air lter element.............................. 6-15

• Checking the engine

idling speed...................................... 6-15

• Checking the throttle

grip free play......................................6-15

• Valve clearance................................ 6-16

• Tires ..................................................... 6-16

• Adjusting the clutch

lever free play ...................................6-18

• Checking the brake

lever free play .................................. 6-19

• Brake light switches........................ 6-19

• Checking the front and

rear brake pads................................ 6-20

• Checking the brake

uid level ...........................................6-20

• Changing the brake uid.............. 6-21

• Drive chain slack.............................. 6-22

• Cleaning and lubricating

the drive chain.................................. 6-23

• Checking and lubricating

the cables........................................... 6-24

• Checking and lubricating

the throttle grip and cable........... 6-24

• Checking and lubricating the

brake and shift pedals.................. 6-24

• Checking and lubricating the

brake and clutch levers..................6-25

• Checking and lubricating the

sidestand........................................... 6-26

• Checking the front fork................. 6-26

• Checking the steering................... 6-27

• Checking the wheel bearings..... 6-28

• Battery ................................................ 6-28

• Replacing the fuses........................ 6-30

• Brake/tail light and the

turn signal light .............................. 6-31

• Auxiliary lights................................. 6-31

• Troubleshooting.............................. 6-31

• Troubleshooting charts ................ 6-33

Displacement	698 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Wheelbase	1505 mm
Max Torque	68 Nm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down fork
Rear Suspension	Swingarm with central shock absorber
Front Brake	Double disc
Rear Brake	Single disc
Weight	220 kg
Tires Front	110/80 R19
Tires Rear	150/70 R17
Engine Type	2-cylinder, 4-stroke, liquid-cooled
