TF02 Operating Manual V1.1
Benewake (Beijing)Co., Ltd.
Page10
5 Steps for quick testing
5.1 Tools for product testing
TF02 (serial
port)
TTL - USB
board
USB cable
Computer
Host computer
software
5.2 Test steps
1) Download the host computer software
Please download TF02_GUI. zip to get the test host computer software from
http://www.benewake.com/en/down.html.
Note: Please close the anti-virus software before decompressing TF host computer. zip; otherwise, the
files in the host computer software will be deleted as viruses; the host computer currently only supports
running on the Windows system.
2) Equipment connection
Figure 3 TF02 connected with a computer
As shown in Figure3, connect TF02, TTL-USB pinboard and USB cable in turn, ensure
no looseness, and then connect the USB cable with the computer.
3) Host computer connection and reading
