PUMP MOT OR POWER
The Submerged Pump Relay Control Signals are rated at 30 watts, 120VAC, or 240VAC maximum. This signal must be wired to an external
Submerged Pump Relay (with all coil control wires for this relay on the same AC phase) for controlling the submerged pump motors. Use Red Jacket
or FE Petrol Control Box or equivalent.
REMOTE DISPENSERS PUMP MOTOR POWER (135047)
A remote relay control wire will be required for each plumbed product. If there is only one product, only one submerged pump control wire is
needed. If there is a second product, a second submerged pump control wire will be needed. Note: Jumpers are factory supplied and installed.
Blue #14 Wire - Product “A” Hose Position
Brown #14 Wire - Product “B” Hose Position
Jumper Wire (Factory Supplied & Installed)
1. Connect the Blue 14ga. wire to the 719 CPU Board at TS2 Terminal 2 or to the optional Junction Box at Terminal 3 as indicated in the diagram.
Connect the other end to the Submerged Pump Control Relay Box for Product A.
2. Connect the Brown 14ga. wire to the 719 CPU Board at TS2 Terminal 3 or to the optional Junction Box at Terminal 4 as indicated in the
diagram. Connect the other end to the Submerged Pump Control Relay Box for Product B.
3. Place 1 blue jumper between P1 to P3 on the 719 CPU and 1 brown jumper between P2 to P4 on the 719 CPU.
SUCTION PUMP MOTOR RELAY
A separate circuit and circuit breaker will be required for each pumping unit motor. Place the pumping unit motor power circuit breakers on the
opposite phase from the dispenser’s electronic power or on 240VAC. This will keep the dispenser’s electronic power free from electronic noise. The
dispenser may have one motor (single product) or two motors (dual product). Each motor requires two or three field wires.
3-PHASE (380VAC) MOTOR A RELAY CONNECTION – PRODUCT A (135049)
Use a 15 AMP 3-phase circuit breaker (CB#2), which is supplied by the customer. Note: No more than 2 pumps per breaker.
Brown #14 – Product “A” Motor Control
Orange #14 – Product “A” Motor Control
Yellow #14 – Product “A” Motor Control
3-PHASE (380VAC) MOTOR B RELAY CONNECTION – PRODUCT B (135049)
Use a 15 AMP 3 phase circuit breaker (CB#2), which is supplied by the customer. Note: No more than 2 pumps per breaker.
Brown #14 – Product “B” Motor Control
Orange #14 – Product “B” Motor Control
Yellow #14 – Product “B” Motor Control
STANDARD SINGLE PHASE (120/240VAC) MOTOR A RELAY CONNECTION – PRODUCT A (135050)
Use a 15 AMP neutral breaking circuit breaker (CB#2), which is supplied by the customer. Note: No more than 2 pumps per breaker.
Blue #14 – Product “A” Motor Control
White #14 – Product “A” Motor Control
Circuit Breaker #2 – Neutral
STANDARD SINGLE-PHASE (120/240VAC) MOTOR B RELAY CONNECTION – PRODUCT B (135050)
Use a 15 AMP neutral breaking circuit breaker (CB#3), which is supplied by the customer. Note: No more than 2 pumps per breaker.
Red #14 – Product “B” Motor Control
White #14 – Product “B” Motor Control
Circuit Breaker #3 – Neutral
BIG FUELER SINGLE PHASE (240VAC) MOTOR A RELAY CONNECTION – PRODUCT A (135085)
Blue #14 – Product “A” Motor Control
White #14 – Product “A” Motor Control
BIG FUELER SINGLE-PHASE (240VAC) MOTOR B RELAY CONNECTION – PRODUCT B (135085)
Red #14 – Product “B” Motor Control
White #14 – Product “B” Motor Control
To Next Page
