Bennett 3722 - Page 9

9 135113 Rev C 4/2/18
2 PRODUCT CONNECTIO N (135046)
16 Field Wires Required
DIRECT PULSE OUTPUT BOARD WIRING
Wiring is to be connected directly to the Pulse Output Board.
OPTIONAL JUNCTION BOX WIRING
Wiring is to be connected to the terminal strip inside the optional junction box.
2
ND
OPTIONAL CONTROLLER
A second optional controller can be used on the RS485 channel. This is used for a Fleet System that uses RS485 for communication and needs the
pulse output signal for a Tank Gauge. Note: Field wiring for the second optional controller can be wired directly to the Pulse Output Board or
through the optional Junction Box. Use the tables below to determine how many wires your optional controller requires for this type of
communication.
 The second optional controller connects to the Pulse Output Board Personality Module.
 RS485 uses a 2-wire protocol.
PULSE OUTPUT BOARD CONNECTION - 2 FIELD WIRES (REQUIRED)
OPTIONAL JUNCTION BOX CONNECTION - 2 FIELD WIRES (REQUIRED)
Qty
Description
Size
Wire Color
To Board
To Terminal
1
(Controller) Pulse Out (+) Product 1
#18
Red
Pulse Output Board
1
1
(Controller) Pulse Out (-) Product 1
#18
Blue
Pulse Output Board
2
1
(Tank Gauge) Pulse Out (+) Product 1
#18
Brown
Pulse Output Board
3
1
(Tank Gauge) Pulse Out (-) Product 1
#18
Pink
Pulse Output Board
4
1
(Controller) Pulse Out (+) Product 2
#18
Red
Pulse Output Board
5
1
(Controller) Pulse Out (-) Product 2
#18
Blue
Pulse Output Board
6
1
(Tank Gauge) Pulse Out (+) Product 2
#18
Brown
Pulse Output Board
7
1
(Tank Gauge) Pulse Out (-) Product 2
#18
Pink
Pulse Output Board
8
1
(Source) In-Use Product 1
#18
Orange
Pulse Output Board
9
1
(Signal) In-Use Product 1
#18
Yellow
Pulse Output Board
10
1
(Source) In-Use Product 2
#18
Black
Pulse Output Board
11
1
(Signal) In-Use Product 2
#18
White
Pulse Output Board
12
1
Authorize Signal Product 1
#18
Black
Pulse Output Board
13
1
Authorize Neutral Product 1
#18
White
Pulse Output Board
14
1
Authorize Signal Product 2
#18
Gray
Pulse Output Board
15
1
Authorize Neutral Product 2
#18
White
Pulse Output Board
16
Qty
Description
Size
Wire Color
To Board
To Terminal
1
(Controller) Pulse Out (+) Product 1
#18
Red
Junction Box
5
1
(Controller) Pulse Out (-) Product 1
#18
Blue
Junction Box
6
1
(Tank Gauge) Pulse Out (+) Product 1
#18
Brown
Junction Box
7
1
(Tank Gauge) Pulse Out (-) Product 1
#18
Pink
Junction Box
8
1
(Controller) Pulse Out (+) Product 2
#18
Red
Junction Box
9
1
(Controller) Pulse Out (-) Product 2
#18
Blue
Junction Box
10
1
(Tank Gauge) Pulse Out (+) Product 2
#18
Brown
Junction Box
11
1
(Tank Gauge) Pulse Out (-) Product 2
#18
Pink
Junction Box
12
1
(Source) In-Use Product 1
#18
Orange
Junction Box
13
1
(Signal) In-Use Product 1
#18
Yellow
Junction Box
14
1
(Source) In-Use Product 2
#18
Black
Junction Box
15
1
(Signal) In-Use Product 2
#18
White
Junction Box
16
1
Authorize Signal Product 1
#18
Black
Junction Box
17
1
Authorize Signal Product 2
#18
Gray
Junction Box
18
1
Authorize Neutral Product 2
#18
White
Junction Box
19
Qty
Description
Size
Wire Color
To Board
To Connection
1
RS485 (+ positive)
#18
Orange
Pulse Output Board
TS4, Terminal 17
1
RS485 (- negative)
#18
Brown
Pulse Output Board
TS4, Terminal 19
Qty
Description
Size
Wire Color
To Board
To Connection
1
RS485 (+ positive)
#18
Orange
Junction Box
Terminal 20
1
RS485 (- negative)
#18
Brown
Junction Box
Terminal 21
