BenQ G2010WP Service Manual

5
3. Product Overview
3.1 Power Supply
Item condition Spec OK NA Remark
Input Voltage range
Universal
input full
range
100~240VAC
√
Input Current range
100Vac
240Vac
1.5A (max.)
0.7A (max.)
√
Power consumption
without Audio,
normal “on”
operation
≤55W
√
LED: Green
DMPS <2W
√
LED: Orange
In rush Current
100Vac,cold
star,25°C;
240Vac,cold
star,25°C
40A (max)
60A(max)
√
To be
determined by
the business
country.
Earth Leakage Current
Hi-pot
Power Line Transient
CCFL Operation range
Power cord
√
3.2 Signal Interface
VGA:
Pin Symbol Pin Symbol Pin Symbol
1 Red+ 6 Red_GND 11 GND
2 Green+ 7 Green_GND 12 DDC_DAT
3 Blue+ 8 Blue_GND 13 Hsync
4 NC 9 5V_VGA 14 Vsync
