BenQ G2010WP Service Manual

8
3.6 Support Timings
Preset Pixel
Format
Horz Freq
(kHz)
Horz
Polarity
Vert Freq
(Hz)
Vert Polarity
Pixel Clk
(MHz)
1 640 x 350 31.47 + 70.09 - 25.18 Preset
2 640 x 350 37.86 + 85.08 - 31.50
Fail safe mode
3 640 x 400 31.47 - 70.09 + 25.18
Non preset
4 640 x 400 37.86 - 85.08 + 31.5
Fail safe mode
5 640 x 480 35.00 - 66.67 - 30.24
Non preset
6 640 x 480 31.47 - 59.94 - 25.17
Preset
7 640 x 480 37.86 - 72.81 - 31.50
Non preset
8 640 x 480 37.50 - 75.00 - 31.50
Preset
9 640 x 480 43.27 - 85.01 - 36.00
fail safe mode
10 720 x 400 31.47 - 70.08 + 28.32
Preset
11 720 x400 37.93 - 85.04 + 35.5
fail safe mode
12 832 x 624 49.71 - 74.53 - 57.27
Preset
13 800 x 600 35.16 + 56.25 + 36.00
Non preset
14 800 x 600 37.88 + 60.32 + 40.00
Preset
15 800 x 600 48.08 + 72.19 + 50.00
Non preset
16 800 x 600 46.88 + 75.00 + 49.50
Preset
17 800 x 600 53.67 + 85.00 + 56.25
fail safe mode
18 848 x 480 31.02 + 60.00 + 33.75
Non preset
19 848 x 480 29.83 - 59.66 + 31.50
Non preset
20 848 x 480 35.00 - 70.00 + 37.52
Non preset
21 848 x 480 36.07 - 72.00 + 39.25
Non preset
22 848 x 480 37.68 - 74.77 + 41.00
Non preset
23 720 x 576 35.83 - 60.00 - 32.71
Non preset
24
1024 x
768-I
35.52 + 43.38 + 44.9
Out of range
mode
25 1024 x 768
48.36 - 60.00 - 65.00
Preset
26
1024 x 768
56.48 - 70.07 - 75.00 Non preset
27 1024 x 768
57.67 - 72.00 + 78.43
Non preset
28 1024 x 768
60.24 - 74.93 - 80.00
Preset
29 1024 x 768
60.02 + 75.03 + 78.75
Preset
30 1024 x 768
68.68 + 85.00 + 94.50 fail safe mode
31 1152 x 720
44.86 - 60 + 66.75
Preset
32 1152 x 864
63.85 + 70.01 + 94.50 Non preset
