10
12.5 Analog RGB Output 15 pin D-Sub (Female) x 1
G(Y): Video amplitude 0.7/1.0 Vp-p : Impedance 75
RB(CbCr): Video amplitude 0.7 Vp-p : Impedance 75
HD/VD/CS: TTL Level
13.0 Control Interface
13.1 IR Receiver
IR Receiver x1 (Front) Angle: ±30° Distance 0~8m
13.2 Serial Connector
RS232 9pin, command table adhere to Appendix
A
14.0 User Interface Adhere to Appendix A
14.1 Operator Keypad
10 Keys:
Power ; Source ; Auto ; Blank ; Menu/Exit ; Left/Q?; Right/Panel
Key lock ; Up(Keystone+) ; Down(Keystone-) ; Mode
14.2 Indicators
3 LEDs:
Power On/Off Status; Lamp Status; Temperature Status
14.3 Electric Keystone
vertical keystone and adjustable range ±25°
