BenQ MP512 - Page 54

54
Fig. 1-6
Fig. 1-7
Fig. 1-8 Fig. 1-9
1.3 Lamp Wire Arrangement
I. Lamp Wire arrangement have to look likes as below(Figure 1-11)
II. Bending Angle have to face to backside of Lamp(Figure 1-12)
Fig. 1-10 Fig. 1-11
F/G datum
Insert to HLD Lamp
Short Wire
Long Wire
Short Wire
Long Wire
