Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
• In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 8). They are commercially available from electronics stores.
• For detailed connection methods, see pages 19-22.
1. VGA cable
2. VGA to DVI-A cable
3. Component Video to VGA (D-
Sub) adapter cable
4. S-Video cable
5. Video cable
6. Audio cable
1 2 1
3
4 5
6
6
6
Notebook or desktop computer
Speakers
or
A/V deviceMonitor
(DVI)(VGA)
(MP515)
(MP525/MP575)
(MP526/MP576)
