Operation 49
Description of each menu
Function
(Default setting/value)
Description
Wall Color
(Off)
Corrects the projected picture's color when the projection
surface is not white. See "Using Wall Color" on page 33 for
details.
Aspect Ratio
(Auto)
There are four options to set the image's aspect ratio
depending on your input signal source. See "Selecting the
aspect ratio" on page 31 for details.
Keystone
(0)
Corrects any keystoning of the image. See "Correcting
keystone" on page 25 for details.
Position
(0)
Displays the position adjustment page. To move the projected
image, use the directional arrow keys. The values shown on the
lower position of the page change with every key press you
made until they reach their maximum or minimum.
This function is only available when a PC signal (analog
RGB) is selected.
Phase
Adjusts the clock phase to reduce image
distortion.
This function is only available when a
PC signal (analog RGB) is selected.
H. Size
(0)
Adjusts the horizontal width of the image.
This function is only available when a PC signal (analog
RGB) is selected.
Digital Zoom
(1.0X)
Magnifies or reduces the projected image. See "Magnifying and
searching for details" on page 31 for details.
Picture Mode
(Presentation)
Pre-defined picture modes are provided so you can optimize
your projector image set-up to suit your program type. See
"Selecting a picture mode" on page 33 for details.
Reference Mode
(Dynamic)
Selects a picture mode that best suits your need for the image
quality and further fine-tune the image based on the selections
listed on the same page below. See "Setting the User 1/User 2
mode" on page 34 for details.
Brightness
(50)
Adjusts the brightness of the image. See "Adjusting Brightness"
on page 34 for details.
Contrast
(0)
Adjusts the degree of difference between dark and light in the
image. See "Adjusting Contrast" on page 34 for details.
1. DISPLAY menu
2. PICTURE menu
