BenQ MP515 - Page 63

Specifications 63
Dimensions
255 mm (W) x 110 mm (H) x 217 mm (D)
Ceiling mount installation
255
217
110
60.23 66
67.00
189.00
100.00
116.00
82.50
50.00
36.69 119.00
PUSH
69.41
111.41 107.28
218.69
84.00
61.00
127.12
255.25
82.50
Ceiling mount screws:
M4 x 8 (Max. L = 8 mm)
Unit: mm
