BenQ MS500+ - Dimensions and Mounting

Specifications 53
Dimensions
287.3 mm (W) x 100.4 mm (H) x 232.6 mm (D)
Ceiling mount installation
287.3
232.6
100.4
62
62
445.95 397.90 364.40
83.38
141.88
232.6
123.0
78
287.3
207.6
77
76.5
34.5
199.6
Ceiling Mount screw:
M4 x 8 (Max L = 8 mm)
Unit: mm
