BenQ MW769 - Dimensions; Ceiling Mount Installation

Specifications 93
Dimensions
329 mm (W) x 137.2 mm (H) x 248.7 mm (D)
Ceiling mount installation
329
248.7
137.2
62.5
77.4
75.0
221.0
100.0
146.0
329.0
163.7
62.5
127.7
329.0
163.7
62.5
577.7
625.95
537.9
25
132.16
115.1
72.87
Ceiling mount screw: M4
(Max L = 25 mm; Min L = 20 mm)
Unit: mm
