BenQ MX613ST - Page 115

115
Chapter 5 - Error Count Messages Definition
Error Count Definition Specification
Lamp Fail Lamp Off Detect LampLit NG
Fan 1 Speed Error Lamp Fan Speed Error Speed Over ± 20%
Fan 2 Speed Error Power Fan Speed Error Speed Over ± 20%
Fan 3 Speed Error Blower Fan Speed Error Speed Over ± 20%
Fan 4 Speed Error DMD Fan(Inlet Fan) Speed Error Speed Over ± 20%
Sensor 1 Open Error Main Board Sensor Error Detect Sensor 1
Sensor 1 Short Error Main Board Sensor Error Detect Sensor 1
Temperature 1 Error Over temperature >53℃
FanIC 1 I2C Error N/A N/A
Color Wheel Error Color wheel operating Error
Abnormal Power down System abnormal power down
Fig. 5-1 Fan and Sensor Placement
