Appendix 1 – Screw List / Torque
Model name : MX613ST
No
.
Screw P/N
Description
Q’T
Y
To r q u e
Where use
Type Head Length Coating (kgf-cm)
M2.5 1 8F.00430.6R0
MAC
H
PH 6 NI 2 4~5 Right case & Speaker(2*)
M3.0
1 8F.VG564.8R0 TAP PH 8 NI 5 6~7
Lamp frame & Connector(1*)
Lower case & Blower BKT(2*)
Lower case & Lamp frame(2*)
2 8F.VG524.6R0 TAP PH 6 NI 5 6~7
Lower case & PWR BD(4*)
Upper case & Zoom/Focus
Cover(1*)
3 8F.VA564.6R0 TAP PH 6 NI 2 6~7
Hook & Front case(1*)
Lower case & Lamp frame(1*)
4 8F.VA564.8R0 TAP PH 8 NI 11 6~7
OM & Lower case(3*)
Upper case & Lower case(5*)
Upper case & Lamp frame(1*)
Lower case & Ballast holder(2*)
5 8F.1D224.5R0
MAC
H
PH 5 NI 11 5.5~6.5
SHD MB & BKT MB(6*)
Blower BKT & Nozzle(1*)
MB & Extension board (4*)
6 8F.00521.001
MAC
H
PH 8 B-NI 1 5.5~6.5 Lamp door & Left case(1*)
M4.0 1 8F.1D526.6R0 MACH
TAPTIL
E
6 NI 4
5.5~6.5
A
C Wire & BKT MB(1*)
5.5~6.5 Lower case for ceiling (3*)
#4-40 1 8F.00649.120 MACH STAND 8 NI 8 4.5~5.5 Rear case & D-SUB(8*)
M3 1 8F.00642.170 MACH STAND 17 Brass 2 5.5~6.5 MB & Extension board (2*)
z Screw Type: 10 types
z Screw quantity: 51
