Model Name : MX613ST (OM)
No
.
P/N
Description
To r q u
e
Where use
Q'ty
Q’ty
Type Head
Lengt
h
Surfac
e
(kgf-c
m)
Unit
M2
1
8F.1A752.3R0 MACH PH 3.0 B-NI
2.5+/-
0.5
SENSOR BD VS BKT CW 1
9
CVR CW VS BKT CW 2
CLIP LP VS HSG DMD 1
BAFFLE LP VS HSG DMD 1
SHIELD CW VS BKT LINK LAMP 1
CLIP CM DOWN VS ILL SUB HSG 1
COVER LAMP VS HLD LAMP 2
1.5+/-
0.5
CVR Anti dust VS BKT CW 1 1
2 8F.1A752.8R0. MACH PH 8.0 B-NI
2.5+/-
0.5
HLD FM VS ILL SUB HSG 1 1
3 8F.00654.001 MACH PH 8.0 B-NI
2.5+/-
0.5
LP Adjustment 2 2
4 8F.8A522.3R5 MACH FPH 3.5 NI
2.2+/-
0.5
RING ZOOM VS LENS 2 2
M2.5
1 8F.00345.5R6. MACH FPH 5.6 NI
3.5+/-
0.5
CW VS. BKT CW 3 3
2 8F.1A723.5R0 MACH PAN 5.0 B-NI
3.0+/-
0.5
ILL SUB HSG VS. DMD HSG 2 2
M3
1 8F.JA754.4R0 MACH FPH 4.0 B-NI
3.0+/-
0.5
PL_FLANGE VS. HSG DMD 3 3
2 8F.1A554.4R0 MACH PAN 4.0 NI
4.5+/-
0.5
CW MODULE VS HSG DMD 1
5
CLIP FG VS HLD LAMP 1
CLIP LAMP VS HLD LAMP 2
FIN VS HLD LAMP 1
3 8F.1A554.5R0 MACH PAN 5.0 NI
4.0+/-
0.5
BKT LINK LAMP VS HSG DMD 2 2
4 8F.1A554.6R0 MACH PAN 6.0 NI
4.0+/-
0.5
LAMP MODULE VS. HSG DMD 1 1
PL FLANGE VS ADAPTE
R
4 4
5 8F.2R754.6R0 MACH HEX 6.0 B-NI
5.0+/-
0.5
CLIP PLATE VS. HLD LAMP 1 1
6 8F.VA564.6R0 MACH PH 6 NI
4.5±0.
5
HLD CONNECTOR VS. CLIP
PLATE
1 1
7 8F.VG564.8R0 MACH PH 8 NI
4.5±0.
5
LAMP WIRE VS. HLD
CONNECTOR
1 1
8 6E.0U101.001
ASSY
SPRIN
G
SCREW
PH 7.5 NI
6.0+/-
0.5
H-Sink VS. DMD HSG 4 4
SUM =42
