Product Overview
The projector consists of DLP projector controller, Lamp controller, Power supply system, and
System cooling controller. The DLP controller captures digital PC data and video data and then
converts them into the DMD display device. The Lamp controller dominates the lamp’s power and
synchronizes its frequency with color display sequence. The Power supply unit controls the AC line
power factor and converts primary voltage to secondary low voltages for digital board. The System
cooling controller drives the airflow to quench the lamp’s heat and electrical component’s heat.
1. Specifications:
1.1 Specification Overview
MX613ST
V
ersion: 0
1
Item Specification
1.Panel Information
1.1 Panel Type 0.55” svXGA 2xLVDS 450 DMD
1.2 Package Type 450 series
1.3 Size 0.55”
1.4 Pixels 1024(H) x 768(V)
1.5 Color Depth 30 Bits (1.07 Billion Colors)
1.6 Driver Type DDP 2431
1.7 Panel Pixel Qualit
y
Follo
w
TI spec.
1.8 Image Imperfection Follow TI spec.
2. Projection Lens Specification (For Reference)
2.1 F/#
W
ide Te l e
2.6 2.78
2.2 Zoom Ratio 1.2±2%
2.3 Throw Ratio 0.9 (Wide 54.5” ±3% @ 1m)
2.4 True Zoom NA
2.5 Focal Length
W
ide: Te l e :
10.2 mm 12.24mm.
2.6 Offset 110%+/-5%
2.7 Visible Focus Range 0.6~8 m
2.8 Clearly Focus Range 0.7~3.5m
2.9 Keystone Distortion
W
ide & Tele <1%
2.9 TV Distortion
W
ide & Tele <1%
2.10 Screen Distortion |A,B| <= 3.0 mm, |C| <= 2.5 mm with 60” image size
2.11 Zoom Ring Torque 120~300g.
2.12 Focus Ring Torque 50~180g
2.13 Center Position Shift(W-T)
(Video Projector only)
N.A.
2.14 Zoom&Focus shaking level Follow typical sample (When needed)
2.15 Lens Shift Shaking Level N.A.
2.16 Lateral Color
Center @ 49” All other area
R
-G <2/3 pixel <1.0 pixel
B-G <2/3 pixel <1.0 pixel
R
-B <1.0 pixel <1.0 pixel
