Blemish around the logo must be equal or smaller than 0.05 mm
2
1.3 表面气泡—不可有。
Bubble on the surface is to be reject.
TABLE 2 :
产品一般外观的塑料件检验标准
(General Product of plastic outlook inspection standard)
NO Appearance Spec
1
缩水
Shrinkage
A 区: 不可有缩水, 以带手套检验, 手摸过去不可有凹
陷的感觉
A region: No Shrink. With gloves, no feeling of sink when touching the surface
B / C 区: 不能明显看出
B/C region: not obvious
2
流痕, 咬
花, 光泽
Run,
Te x t u r e ,
Gloss
不能有明显的深浅不均
No obvious non-uniformity
3
接合线
Wel di ng
Line/Knit
Line
用指甲划过不会有停顿感,并附近无明显之光泽差异
When scratching on it, there’s no feeling of obstruction. Also, there should not be obvious
difference in gloss nearby it.
4
顶白
Ejector
Mark
不可
Reject
5 Label/screw
s shortage
不允许
Reject
6
缺料
Material
shortage
缺料不可影响机构强度和表面
Material shortage is not allowed to impact structure strength and surface
7
色差
Chromatic
aberration
喷漆(Painting): ΔE<=2; L<=1.5 ; Δ A,B <= 0.6
银粉漆 (Paint, aluminum).
ΔE<=2 L<=1.0; Δ A, B <= 0.6
非银粉漆(Paint, non-aluminum)
素材(Raw material) : ΔL,A,B<=0.6 ,ΔE<=0.75
8
印刷
Printing
文字印刷不得有漏印、断线、重影、组细不均、溢墨、印偏( 1mm )、印斜 (歪斜＜0.3
mm )。
Printing must not have incomplete printing, break off, overlap, uneven thickness,
excessive ink, printing misalignment (1mm), printing slanting & crooked
(<0.3mm)
文字印刷颜色须确认是否正确 。
Printing color must be comparable to color chip and sample.
9 Logo of
panel
sticker
文字印刷不得有漏印.断线.重影.组细不均.溢墨.印偏( 1mm)印斜 (歪斜 ＜ 0.5 mm).
Printing must not have incomplete printing, break off, overlap, uneven thickness, excessive
ink, printing misalignment (1mm), printing slanting & crooked (<0.5mm)
文字印刷颜色须确认是否正确.
Printing color must be comparable to color chip and sample.
10
刮伤
Scratch/Nic
ks
Side A:
(W < 0.1mm , L < 3mm): 容许 2 个
Only 1 this kind of scratch is accepted
W < 0.1mm , L < 3-5mm 容许 1 个
No this kind of scratch is accepted
Side B:
W < 0.15mm , L < 3mm 容许 3 个
Only less than 2 this kind of scratch is accepted
W < 0.15mm , L < 3-5mm 容许 2 个
Only 1 this kind of scratch is accepted
Side C:
