73
Fig. 1-6 Fig. 1-7
Fig. 1-8 Fig. 1-9
2. Assembly FM Module:
2.1 Place FM on “HLD FM” surface(Fig. 2-1) and use “Clip FM” to fix FM(Fig. 2-2).
Fig. 2-1 Fig. 2-2
Touch the side surface
Clip FM hook
the punch points
1. Place Clips
on BKT surface
2. Push Baffle LP
to hook DMD HSG
Push on the left corner until lock
the screw well
Lock the screw well
