8
ECO Mode
170W
5. Mechanical Specification
5.1
Color & Texture
specifications Refer to ID document for details
5.2 Physical
Dimensions(Width X
Depth X Height)
311.81mm x 244.12mm x 104.07mm
5.3 Gross Weight
≤2.80kg (TBD)
5.4 Security Slot Kensington compatible slot 20Kg break away force
5.5 Lens Cover Detached lens cover
5.6 Adjustment Feet
Fast adjustable foot in front, Adjustable foot in rear.
Front/ Rear foot Tilt: 0-8∘,Right/Left: +2.2∘/-0.5∘
5.7 Ceiling Mounting
Match BenQ’s ceiling mount required.
Use the same mounting as current shipping projectors.
5.8 Screws
ll color of screws should similar with the plastic color which
close it.
5.9 During PVT stage, limited sample
of color and texture should be
approved by BenQ industrial
designer and mechanical
engineer.
N/A
6. Packaging
6.1 Box Dimension 400 x 345 x 188
mm (W x H x D)
6.2 Net Weight (Esti.)
≤ 2.80kg (TBD)
6.3 Gross Weight (Esti.) <
4.00kg (Including Accessories, Projector)(TBD)
6.4 Container Loading (40') 2016 (TBD)
6.5 Container Loading (20') 1008 (TBD)
6.6
Packaging Conceptual
Refer
Packing Description and Appearance Description
6.7
Container Layout
Refer
Packing Description
and Appearance Description
6.8
Cushion Orientation Refer
Packing Description and Appearance Description
6.9
Cushion Material
EPE
6.10
Box Compression Test
N/A
6.11 Carton Artwork
Refer
Packing Description and Appearance Description
7. Thermal Specification
Mechanical component temperature at ambience 0~40℃
7.1 Surface held or touched for short
periods
Normal surface:
Metal< 60 ℃ Plastic< 85 ℃
Bottom surface @25℃
Metal< 55 ℃ Plastic< 70 ℃
7.2 Surface which my be touched
Metal
Plastic
< 70 ℃ < 95 ℃
7.3 Exhaust Air
< 95 ℃
7.4 Audible Noise Level
Typical
Normal mode: 33dBA @ 25°C(table center)
Eco mode: 29dBA @ 25°C(table center)
Max.
Normal mode: 35dBA @ 25°C(table center)
Eco mode: 31dBA @ 25°C(table center)
7.5 Fan Numbers
4
8.0 Power Requirements
8.1 Power Supply (Normal)
8.2 Power consumption
Max.
336W
Standby
1W Max. at 100 ~ 240VAC
