Assemble “Ring Zoom” (Fig. 10-9).
i. Pre-fastening two Screws firstly (Fig. 7-9-1)
ii. Fastening the two Screws (Fig. 7-9-2)
Fig. 7-9-1 Fig. 7-9-2
Screws
Insert Screws
Ring Zoom
Ring Zoom
Pre-fastening
