Connection20
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
In the connections shown below, some cables may not be included with the projector (see "Shipping contents"
on page 8). They are commercially available from electronics stores.
• Many notebooks do not turn on their external video ports when connected to a projector. Usually a key
combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/
LCD or a function key with a monitor symbol on the notebook. Press FN and the labeled function key
simultaneously. Refer to your notebook's documentation to find your notebook's key combination.
1. VGA cable
2. VGA to DVI-A cable
3. USB cable (B to A type)
4. HDMI cable
5. S-Video cable
6. Video cable
7. Audio cable
8. Audio L/R cable
9. USB cable (mini B to A type)
